Description
18oz 22oz Stainless Steel Bottle with phone holder
Mechanical mounting instead of magnets
A phone holder on a bottle can be built two ways: magnetic, or mechanical. The magnetic approach uses a plate or a ring of neodymium magnets and depends on the phone having a compatible back or a metal plate attached. The mechanical approach uses a clamp, a strap, or a cradle that grips the phone by its edges.
Mechanical mounting is bulkier and works with any phone, in any case, without the user having to attach anything to it. That is a real advantage in a B2B gift or promotional context, where the recipient will not install an accessory.
Clamp, strap, or cradle
A spring clamp grips the phone on two sides and needs a spring strong enough to hold a 250 gram phone but light enough to open with one hand. A strap wraps around the phone and is the most universal and the least convenient. A cradle holds the phone in a pocket with a lip at the base, which is the most secure and the most size-dependent.
A cradle sized for 140 to 165mm phone length and 70 to 85mm width covers most current devices. Outside that range, the fit fails.
Phone size ranges and tolerance
Phone dimensions vary more than most accessory designers assume, and cases add 2 to 4mm per side. A cradle designed to the nominal phone size will not accept a phone in a rugged case, which is exactly the phone a person takes outdoors.
Specify the internal dimensions with the case allowance built in, and test with three cases: bare, slim, and rugged.
Load path through the bottle wall
The holder is attached to a bottle that may be full and heavy, and the phone adds a lever arm at the top. A holder bonded or clipped to a thin bottle wall will flex the wall and, over time, crack the coating or the wall itself.
The attachment should spread load over a wide area, and it should attach near the shoulder where the wall is supported, not at mid-height where it can flex.
Testing before you ship
Three tests: hold a 250g weight in the holder and shake the bottle for a minute; insert and remove a phone in a rugged case twenty times; and drop the assembled unit from waist height onto concrete with the phone fitted. A holder that passes all three will not generate returns. One that passes only the first will.
